TestEquity 1007C - Major Electrical Parts

Chapter 9 – Maintenance
TestEquity 1007C Temperature Chamber Page 9-13
Major Electrical Parts
Description
Mfr
Mfr Part No.
Ref #
Part #
Qty
UOM
Audible Alarm
Floyd Bell
MC-09-201-Q
AL1
200005
1
ea
Arc Suppressor
ITW Paktron
104MACQRL150
AS1
200296
1
ea
Contactor, 3 P 30A
Hartland
HCC-3XT02SX
C1-3
200245
3
ea
Relay, Octal DPDT 10A 120VAC
Idec
RR2P-UCAC120
CR1-2
200292
2
ea
Disconnect Switch, 3 Pole, 45A
ABB
OT63F3
DSW
200281
1
ea
Fuse, 4A
Bussman
FNQ-R-4
F1, 2
200083
2
ea
Fuse, 15A
Bussman
FNQ-R-15
F3-4
200188
2
ea
Fuse, 15A
Bussman
LP-CC-15
F5-8
200187
4
ea
Fuse, 3A
Bussman
FNM-3
F11
200186
1
ea
Circulator Motor Kit
CUSTOM
CUSTOM
FM3
100575
1
ea
Heat Limiter Assembly
Thermodisc
G5A-01-240C with QC Terminals
HL
222253
1
ea
Heater, Air
CUSTOM
CUSTOM
HT1
200181
1
ea
Appliance Light, 40W, 120V
Generic
Generic
LT1
300096
1
ea
Indicator, Panel, 240V Neon
SoLiCo
S412-2-1-N2
PL1
200026
1
ea
Indicator, Panel, 120V Neon
SoLiCo
S412-2-1-N1
PL2
200025
1
ea
Solid State Relay, 25A, 3-32VDC In
Siemens
SSRT-240D25
SSR1
200021
1
ea
Solid State Relay, 10A, 5VDC In
Omron
G3NE-210T-US DC5
SSR2-3
200129
2
ea
Switch, SPST, Rocker
Carlingswitch
LRA211-RA-B/125N
SW1
200023
1
ea
Switch, ON-OFF-ON
Carlingswitch
RC911-RA-B-0-N-XLR1
SW2
200275
1
ea
Temperature Controller
Watlow
F4SH-CKA0-01AE
TCR1
200001
1
ea
High/Low Limit Controller
Watlow
PM6L1AJ-AAAABAB
TCR2
200301
1
ea
Timing Module
Airotronics
THC1030SC
TM1
200243
1
ea
Control Transformer
Hammond
PH350MLI
TR1
200219
1
ea
60 Hz Low or High Line Option
Transformer
Acme Electric
T-1-81050
TR2, 3
200060
2
ea
50 Hz Option
Transformer
Hammond
QC50ESCB
TR2, 3
200124
2
ea
Chart Recorder Option
Recorder, 1 Pen, 10"
Honeywell
DR4301-0000-G0100
RCD1
200094
1
ea
Chart paper, -90 to 210 C
Honeywell
24001660-034
200095
1
ea
Chart paper, -130 to 410 F, Alternate
Honeywell
24001660-033
200096
1
ea
Pen, Purple, Six Pack
Honeywell
30735489-007
200097
1
ea
