Chapter 4 – Temperature Controller
Page 4-12 TestEquity 1007C Temperature Chamber
Profile Examples
The following are examples of two typical profiles Note that Digit Out 1 is named CONDITION.
Profile Summary: -40ºC to 85ºC, no ramps, 30 minute soak time, 4 cycles. End with program hold at +23ºC.
Step Step Date Choose Digit Out Time Ch1 PID Guar. Jump to End
Number Type Day, Time Wait for 1 2 3 4 5 6 7 H:M:S Rate SP Set Soak Profile Step Repeats Type
1 Ramp Time — > > > > > > > > 00:00:01 — 23.0 1 — — — — —
2 Ramp Time — > > > > > > > > 00:00:01 — -40.0 1 — — — — —
3 Soak — > > > > > > > > 00:30:00 — — 1 Yes — — — —
4 Ramp Time — > > > > > > > > 00:00:01 — 85.0 1 — — — — —
5 Soak — > > > > > > > > 00:30:00 — — 1 Yes — — — —
6 Jump — > > > > > > > > — — — — — Name 2 3 —
7 Ramp Time — > > > > > > > > 00:00:01 — 23.0 1 — — — — —
8 End — — — — — — — — — — — — — — — — — Hold
Step Description
1 Establishes a recommended initialization step. Goes to +23ºC as quickly as possible.
2 Goes to -40ºC as quickly as possible.
3 Will hold for 30 minutes. Time will not start until chamber reaches -37ºC (within the 3º Guaranteed Soak Band*).
4 Goes to +85ºC as quickly as possible.
5 Will hold for 30 minutes. Time will not start until chamber reaches +82ºC (within the 3º Guaranteed Soak Band*).
6 Jumps back to step 2. Repeats this 3-times, for a total of 4-cycles.
7 After all cycles are completed, establishes the condition to end on. Goes to +23ºC as quickly as possible.
8 Holds at +23ºC indefinitely, until program is manually stopped.
Profile Summary: +50ºC to 0ºC, 1ºC/minute ramp, 1 hour soak time, 100 cycles. Test sample turned ON/OFF depending on step. End with return to +23ºC manual set point.
Step Step Date Choose Digit Out Time Ch1 PID Guar. Jump to End Idle
Number Type Day, Time Wait for 1 2 3 4 5 6 7 H:M:S Rate SP Set Soak Profile Step Repeats Type SP
1 Ramp Time — > On > > > > > > 00:00:01 — 23.0 1 — — — — —
2 Ramp Rate — > On > > > > > > — 1.0 50.0 1 — — — — —
3 Soak — > On > > > > > > 01:00:00 — — 1 No — — — —
4 Ramp Rate — > Off > > > > > > — 1.0 0.0 1 — — — — —
5 Soak — > Off > > > > > > 01:00:00 — — 1 No — — — —
6 Jump — > > > > > > > > — — — — — Name 2 99 —
7 Ramp Rate — > Off > > > > > > — 1.0 23.0 1 — — — — —
8 End — — — — — — — — — — — — — — — — — Idle 23.0
Step Description
1 Establishes a recommended initialization step. Goes to +23ºC as quickly as possible. Test sample is turned ON via Event 1.
2 Goes to +50ºC at a controlled rate of 1ºC per minute. Test sample is turned ON via Event 1.
3 Will hold for 1 hour. Test sample remains ON via Event 1.
4 Goes to 0ºC at a controlled rate of 1ºC per minute. Test sample is turned OFF via Event 1.
5 Will hold for 1 hour. Test sample remains OFF via Event 1.
6 Jumps back to step 2. Repeats this 3-times, for a total of 4-cycles.
7 After all cycles are completed, establishes the condition to end on. Goes to +23ºC at a controlled rate of 1ºC per minute. Test sample is turned OFF via Event 1.
8 End of program. Controller returns to a +23ºC manual set point.. Test sample is remains OFF via Event 1.
Notes
* Guaranteed Soak Band is set at the factory for 3.0ºC. Can be changed in the System Menu.
> Means no entry or selection is required. Just scroll through this prompt to the next prompt.
— Means prompt does not show for this step type.
