Chapter 9 – Maintenance
TestEquity 1007C Temperature Chamber Page 9-17
Series F4 Operations Parameters
PID Set Channel 1 Menu
Main Page\Go to Operations\Edit PID\PID Set Channel 1\
PID Set (1-5)
Proportional BandA 5.0 °C (9.0 if °F)
Reset A 0.05 min
Rate A 0.00 min
Dead Band A 0.0 °C
Proportional BandB 5.0 °C (9.0 if °F)
Reset B 0.05 min
Rate B 0.00 min
Dead Band B 0.0
Alarm Setpoints Menu
Main Page\Go to Operations\Alarm Setpoints\Alarm1
Alarm1 Low SP -75.0°C (-103.0° if °F)
Alarm1 High SP 175.0 °C (347.0 if °F)
Main Page\Go to Operations\Alarm Setpoints\Alarm2
Alarm2 Low SP -75.0°C (-103.0° if °F)
Alarm2 High SP 175.0 °C (347.0 if °F)
NOTE: The alarm outputs of the Temperature Controller are NOT
connected to the chamber’s safety system. TestEquity does NOT
recommend using the Temperature Controller’s alarm function as the
Series F4 Set Lockout Parameters
The Series F4 Controller has several levels of security to prevent unauthorized users from
changing critical configuration parameters. Only the Set Point and Profile menus have “Full
Access”. TestEquity has configured all other menus to “Password”, and have protected them
with a password.
TestEquity does not recommend that these security levels be changed for most applications.
However, there will be times when “Full Access” is necessary. For example, you may need to
gain access to Setup Page in order to change from °C to °F display, or to change the time or date.
You must call TestEquity at 877-512-3457 or 805-480-0638 to obtain the password.
Set Lockout Menu
Main Page\Go to Factory\Set Lockout
Set Point Full Access
Oper. Autotune PID Password
Oper. Edit PID Password
Oper. Alarm SP Password
Profile Full Access
Setup Password
Factory Password
