TestEquity 1007C - Series F4 Setup Parameters

Chapter 9 – Maintenance
Page 9-16 TestEquity 1007C Temperature Chamber
Series F4 Setup Parameters
System Menu
Main Page\Go to Setup\System
GSB 1 Source Input 1
Guar. Soak Band 1 3.0 °C (5.4 if °F)
Current Time (local time)
Current Date (local date)
PID Units US, Reset/Rate
°F or °C °C
Show °F or °C Yes, Upper Display
Ch1 Autotune SP 90%
Input 1 Fail 0%
Open Loop Ch1 Off
Power-Out Time 10 Sec
Power-Out Action Continue
Analog Input Menu
Main Page\Go to Setup\Analog Input1
Sensor Thermocouple
Type T
Decimal 0.0
SP Low Limit -75.0 °C (-103.0 if °F)
SP High Limit 175.0 °C (347.0 if °F)
Calibration Offset 0.0
Filter Time 1.0 sec
Error Latch Self-Clear
Digital Input Menus
Main Page\Go to Setup\Digital Input (1-4)
Name No
Function Off
Control Output Menus
Main Page\Go to Setup\Control Output 1A
Function Heat
Choose Cycle Time Fixed Time
Enter Cycle Time 3.0 sec
Hi Power Limit 100 %
Low Power Limit 0 %
Main Page\Go to Setup\Control Output 1B
Function Cool
Choose Cycle Time Fixed Time
Enter Cycle Time 5.0 sec
Hi Power Limit 100 %
Low Power Limit 0 %
Alarm Output Menus
Main Page\Go to Setup\Alarm Output
(1-2)
Name No
Alarm Type Process
Source Input 1
Latching Alarm Self-Clears
Silencing Yes
Hysteresis 1.7 °C (3.0 if °F)
Alarm Sides Both
Alarm Logic Open on Alarm
Show Message Yes on Main Page
NOTE: The alarm outputs of the
Temperature Controller are NOT connected
to the chamber’s safety system. TestEquity
does NOT recommend using the
Temperature Controller’s alarm function as
the main protection device.
Retransmit Output Menu
(if retransmit option is ordered)
Main Page\Go to Setup\
Retransmit Output 1
Retransmit Source Set point 1
Analog Range 0-5V
Low Scale -75.0°C (-103.0 if °F)
High Scale 175.0°C (347.0 if °F)
Scale Offset 0.0
Main Page\Go to Setup\
Retransmit Output 2
Retransmit Source Input 1
Analog Range 0-5V
Low Scale -75.0°C (-103.0 if °F)
High Scale 175.0°C (347.0 if °F)
Scale Offset 0.0
Digital Output Menu
Main Page\Go to Setup\
Digital Output (1-7)
Name No
Function Event Output
Main Page\Go to Setup\
Digital Output 8
Function Compressor
Comp. On % Power -2%
Comp. Off % Power 2%
Compressor Off Delay 60 sec
Compressor On Delay 10 sec
Communications Menu
Main Page\Go to Setup\
Communications
Baud Rate 9600
Address 1
Custom Main Page Menu
Main Page\Go to Setup\
Custom Main Page
P1 Current File
P2 Current Step
P3 Set Point 1
P4 Step Type
P5 Target SP1
P6 WaitFor Status
P7 Time Remaining
P8 Digital Outputs
P9 % Power 1
P10 Digital Inputs
P11 Date
P12 Time
P13 Custom Message 1
P14 None
P15 None
P16 None
Static Message Menu
Main Page\Go to Setup\
Static Message
Message 1 TESTEQUITY 1007C
