Chapter 4 – Temperature Controller
TestEquity 1007C Temperature Chamber Page 4-7
How to Program a New Profile
1. Go to the Profiles Page.
Move the cursor down the Main Page to
Go to Profiles, then press the ► key.
Main Page_____________
► Go to Profiles ▲
Go to Setup
█
Go to Factory ▼
2. Create a new Profile.
The cursor will be on Create Profile. Press
the ► key.
Main>Profile__________
► Create Profile
Edit Profile
█
Delete Profile ▼
3. Name the profile.
You can name your profiles for easy reference if
desired. Names can have up to 10 characters. You
can also use one of the default profile names (ex.
Profile1), and skip this step. To name a profile:
• Press ► to enter the name space and the first
position.
• Press the ▲or ▼ to scroll through the alphabet
and stop at the letter or number desired.
• Press ► to move to the next position.
• Continue until the name is complete, or until you
move through the name space into the next screen.
• Press ► to save the name of the profile.
Choose to Name:_____
No
► Yes
Enter Profile Name:_
PROFILE1
▲
▼ Adjusts Char
◄► Save Changes
4. Choose the step type.
• There are five step types, each of which must be
defined through different parameters. (See “Step
Types,” earlier in this chapter.)
Choose Step1 Type:____
Autostart
► Ramp Time
█
Soak ▼
5. Define each step type.
• The Series F4 prompts you to define the
parameters of each step type. (See “Step Types,”
earlier in this chapter.)
(Not all choices are shown in this example)
Choose to wait:_______
► Step does not wait
Step waits for...
Choose DIGIT OUT1:____
► Off
On
Enter Ramp Time:______
00:00:01 (H:M:S)
▲
▼ Adjusts Digit
◄► Save Changes
Enter Ch1 SP:_________
85.0 °C
▲
▼ Adjusts Value
◄ Back ► Next
6. Choose the end-state.
• All profiles end with an End step, which is
preprogrammed into the new profile. (See “End
Step,” earlier in this chapter.)
Choose End State:_____
Control Off ▲
All Off
█
► Idle
7. Save your settings.
• Press ◄ to exit the Profiles Page.
• After exiting the Profiles Page, choose ▲ to save
profile data.
Save profile data
or restore values?
▼ Restore ▲ Save
