Chapter 4 – Temperature Controller
Page 4-14 TestEquity 1007C Temperature Chamber
Operations Page
The Operations Page provides access to menus for control tuning (PID) and controller alarms.
TestEquity has configured the security to require a password for access to all parameters in the
Operations Page. You must call TestEquity at 877-512-3457 or 805-480-0638 to obtain the
password.
! CAUTION: The Series F4 Temperature Controller “Alarm” functions are NOT used in the
chamber’s safety system and are NOT connected. TestEquity does NOT
recommend using the Series F4 alarm function as the main protection device.
The independent EZ-Zone Limit Controller functions as the main protection
device.
! CAUTION: The Series F4 Temperature Controller PID values have been properly
configured by TestEquity to match the chamber’s system requirements and to
perform optimally over a wide range of operating conditions. Improper
modifications to these values can result in erratic performance and unreliable
operation. Do not attempt to modify the PID values, unless you thoroughly
understand what you are doing. Setup examples in the “Series F4 User’s
Manual” are NOT applicable to this chamber. If there is any doubt, please call
TestEquity before proceeding. The correct values are documented in the
“Series F4 Temperature Controller Setup Parameters” section of this manual.
! CAUTION: The Autotune PID function is not appropriate for use in this chamber. Using
this function will result in tuning values that will not work correctly.
Setup Page
The Setup Page provides access to menus for configuring the controller hardware. TestEquity
has configured the security to require a password for access to the Setup Page. However, there
will be times when entry into these menus is necessary. For example, you may need to gain
access to Setup Page in order to change from °C to °F display, or to change the time or date. You
must call TestEquity at 877-512-3457 or 805-480-0638 to obtain the password.
! CAUTION: The Series F4 Temperature Controller setup values have been properly
configured by TestEquity to match the chamber’s system requirements and to
perform optimally over a wide range of operating conditions. Improper
modifications to these values can result in erratic performance and unreliable
operation. Do not attempt to modify the setup values, unless you thoroughly
understand what you are doing. Setup examples in the “Series F4 User’s
Manual” are NOT applicable to this chamber. If there is any doubt, please call
TestEquity before proceeding. The correct values are documented in the
“Series F4 Temperature Controller Setup Parameters” section of this manual.
