6 Using the product
29
Parameters Explanation
Flow rate correction
factor
Due to pressure drops in the system, the measured
volume flow may be smaller than the actual volume
flow.
The measured volume flow can be corrected via the
flow rate correction factor.
The flow rate correction factor has a directly
proportional effect on the measurement result and is
usually set at 1.00. Once the factor is changed, the
result is multiplied by the flow rate correction factor.
Pitot tube factor See Section 6.6.6.
Channel geometry Entering a channel geometry is required if the
operating or standard volumetric flow needs to be
determined.
You can choose between round and square channel
shape (confirm selection with [ ]).
As well as the direct channel shape, the "c factor"
function (see Section 6.6.9) or funnel can also be
selected (see Section 6.6.7)
Electrical power The electrical power can be set in W, kW or BtU/h.
This data is purely for informational purposes and is
not incorporated in any measurement result.
4. Finalise the entry: [ ] → Save and close.
Other measuring point options
> [ ] → Select measuring point: measuring point is selected
and displayed in the status line in the measuring view. Reports
are saved under the selected measuring point.
> [ ] → Edit measuring point: make changes to an existing
measuring point.
> [ ] → Delete measuring point: delete an existing measuring
point, including the measurement protocols saved for it.
> [ ] → New measuring program: determine parameters for a
new custom measurement. To create a new measuring
program, see Grid measurement, page 32
> [ ] → New grid measurement: carry out grid measurement,
see Turbulence measurement, page 37.
> [ ] → New turbulence measurement: carry out turbulence
measurement, see Measuring program, page 31
> [ ] → New PMV/PPD measurement: Carrying out a
PMV/PPD measurement, see Grid measurement, page 32.
