6 Using the product
43
Parameters Explanation
Electrical power Input optional, parameter is not
taken into account for this
calculation.
Optional entries are listed in the protocol.
3. Enable measuring point: → Save and select
4. Create new measuring program: → New measuring
program
> Perform settings: See Measuring program, page 31.
5. Save settings:
→ Save and close
- The newly created measuring program is marked in Explorer.
6. Switch to the measuring view: Press [Esc].
7. Check whether the parameters reference volume flow and/or
differential pressure appear in the Favourites tab.
8. Position the instrument ready for measurement and stabilize.
The differential pressure parameter display depends on
the position of the pressure sensor. The parameter
display must be zeroed.
9. Zero pressure sensor: Press [ ] to select the INT tab → →
[ ] → Zero → [ ]
> Attach the measurement hoses to the instrument's differential
pressure connections and at the position specified by the
manufacturer.
10. Select the previously created measurement program in
Explorer.
11. Start measuring program: [ ]→ → Start measuring
program → [ ].
6.6.10. CO
2
measurement
• The CO
2
probe measures the absolute pressure. The displayed
CO
2
value is compensated automatically in line with the
absolute pressure.
• Due to the sensor, the probe has a relatively high power
consumption. For continuous measurements, use a mains unit
for the power supply.
