6 Using the product
52
6.6.3. Printing measurement values
Selection of the additional information that should be
included on a measurement value printout, see
Performing
settings, page 20.
From measuring mode
✓ testo printer (0554 0549) is switched on.
✓ Required tab has been selected.
1. Align IR interfaces on the top of the testo 480 and testo printer.
2. Select [ ] → Print.
- The set measuring view and are displayed.
- Printout of the currently displayed readings is generated.
CAUTION
Risk of injury from infrared beam!
> Do not direct infrared beam at human eyes!
From the instrument memory
✓ testo printer (0554 0549) has been switched on.
1. Press [ ].
2. Navigate to the saved measuring protocol.
3. Select [ ] → Open measurement protocol.
- Measurement data view is opened.
4. Align IR interfaces on the top of the testo 480 and testo printer.
5. Select [ ] → Print.
- The printout is generated.
The saved measurement protocols can also be displayed
via the testo EasyClimate software.
6.6.4. Display measuring values graphically
Measuring values of max. four measurement parameters can be
displayed as a colour graphic over a period of 110 seconds. In the
case of longer time frames, the oldest values are deleted and
replaced by the new ones. The graphic mode is purely a display
mode, i.e. the measuring values cannot be stored.
