4. Menu
4.1 Accessibility
When browsing the menus there are 3 access levels, of which 2 require password entry:
U User: always visible
S Installer: visible if the maintenance password has been entered (for sole use of TEXA authorised personnel)
M Manufacturer: visible if the manufacturer password has been entered (for sole use of TEXA designers)
4.2 Menu Access
With the machine on, the main screen displays the regulation temperature.
Withthemachineo󰀨,themainscreendisplaysthe“ON/Stand-by”iconandtheregulationtemperature.
A short press of the SET key provides access to the COO parameter for setting of the Set Point.
A long press of the SET key enters the “User” menu level.
Press the UP or DOWN keys to navigate between the menus.
Press the SET key to access the selected menu.
Pressing the ON/Stand-by key exits the active menu.
4.3 List of Menus
The available menus are as follows:
SEt Provides access to the regulation Set Points quick setting
ALM Displays the list of current alarms
PAr Displays/allows editing of the device parameters
OHr Displays the hours of operation of the device and components
HiS Displays the alarms history
nFo Displays device information
PSS Used to enter the passwords for access to the “Maintenance” and “Manufacturer” levels
CoL For starting the testing sequence
4.3.1 PAr Menu
InthePArmenu,theparametersaregroupedonthebasisoffunction(identiedonthedisplaywithalabel),whileeachparameterincorporatesanalpha-
betical index followed by 2 digits, in accordance with the following table:
Group Identifying label Parameter index
General PG G
Alarms PA A
I/O PI I
Regulation Pr r
Compressors PC C
Condensing fans PF F
Evaporator fan PP P
Electrical heating element PH H
4.3.2 OHr Menu
The OHr menu displays the hours of operation of:
Index Component
Ou Unit
OC1 Compressor 1
OP Evaporator fan
OF1 Condensing fan 1
OFi Filter
