A.3 AFE4500 Bill of Materials
Table A-1. Bill of Materials
Designator Quantity Value Description PackageReference PartNumber Manufacturer Alternate
PartNumber
Alternate
Manufacturer
!PCB1, !PCB2, !
PCB3, !PCB4
4 Printed Circuit Board DC126 Any
C1, C3, C4 3 2.2uF CAP, CERM, 2.2 uF, 6.3 V, +/-
20%, X5R, 0201
0201 CL03A225MQ3CR
NC
Samsung Electro-
Mechanics
C2, C20 2 100pF CAP, CERM, 100 pF, 50 V, +/-
10%, X7R, AEC-Q200 Grade 1,
0201
0201 CGA1A2X7R1H10
1K030BA
TDK
C5 1 1uF CAP, CERM, 1 uF, 10 V, +/- 20%,
X5R, 0201
0201 CL03A105MP3NS
NC
Samsung Electro-
Mechanics
C6, C7, C8 3 4.7uF CAP, CERM, 4.7 uF, 6.3 V, +/-
20%, X5R, 0201
0201 GRM035R60J475
ME15D
MuRata
C9, C10, C13, C14 4 2200pF CAP, CERM, 2200 pF, 50 V, +/-
5%, X7R, 0402
0402 CL05B222JB5NNN
C
Samsung Electro-
Mechanics
C11, C12, C17,
C18, C24, C25,
C40, C41, C42,
C45, C52
11 10uF CAP, CERM, 10 µF, 10 V,+/-
20%, X5R, 0402
0402 0402ZD106MAT2A AVX
C15, C16, C19,
C23, C26, C27,
C28, C29, C30,
C31, C32, C33,
C34, C38, C39,
C43, C44, C46,
C47, C49, C50,
C51, C58, C60,
C61, C90, C91,
C92, C93, C94,
C95
31 0.1uF CAP, CERM, 0.1 uF, 10 V, +/-
10%, X5R, 0201
0201 CL03A104KP3NN
NC
Samsung Electro-
Mechanics
C21, C22, C56 3 4.7uF CAP, CERM, 4.7 uF, 10 V, +/-
10%, X5R, 0402
0402 C1005X5R1A475K
050BC
TDK
C35, C36, C37 3 10uF CAP, CERM, 10 uF, 25 V, +/-
20%, X5R, 0603
0603 C1608X5R1E106M
080AC
TDK
C48 1 0.47uF CAP, CERM, 0.47 uF, 6.3 V, +/-
10%, X5R, 0201
0201 CL03A474KQ3NN
NC
Samsung Electro-
Mechanics
C53 1 1000pF CAP, CERM, 1000 pF, 25 V, +/-
10%, X5R, 0201
0201 C0603X5R1E102K
030BA
TDK
C54, C55, C57,
C59
4 10pF CAP, CERM, 10 pF, 25 V, +/- 5%,
C0G/NP0, 0201
0201 GJM0335C1E100J
B01D
MuRata
