Table A-1. Bill of Materials (continued)
Designator Quantity Value Description PackageReference PartNumber Manufacturer Alternate
PartNumber
Alternate
Manufacturer
D1, D2, D3, D4,
D5, D6, D7, D8,
D9, D10, D11, D12,
D13, D14, D15,
D16, D17, D18,
D19, D20
20 1-Channel ESD Protection Diode
for USB Type-C and Thunderbolt
3, DPY0002A (X1SON-2)
DPY0002A TPD1E01B04DPY
R
Texas Instruments TPD1E01B04DPY
T
Texas Instruments
D21, D22 2 Diode Schottky 30V 2A Surface
Mount SOD-123FL
SOD-123F NRVB230LSFT1G ON Semiconductor
D23 1 Super Red LED, Super Red, SMD LED, 1.6x.6x.8mm SML-LX0603SRW-
TR
Lumex
D24, D25, D26 3 Green LED, Green, SMD LED, GREEN, 0603 SML-LX0603GW-
TR
Lumex
H1, H2, H3, H4,
H5, H6, H7, H8
8 Bumpon, Hemisphere, 0.44 X
0.20, Clear
Transparent Bumpon SJ-5303 (CLEAR) 3M
H9 1 10 Pin to 10 Pin HRM Sensor
Cable
Used in PnP output
and some BOM reports
402320148 Biometric - -
H10 1 Cable, USB-A to micro USB-B,
0.3 m
AK67421-0.3 Assman WSW
H11, H12 2 3 WAY ECG Cables Used in PnP output
and some BOM reports
ECG-PRO-3-WAY-
CABLE
Olimex - -
J1 1 Header, 100mil, 12x2, Gold, TH 12x2 Header TSW-112-07-G-D Samtec
J2 1 Header, 2.54mm, 10x1, Tin, R/A,
TH
Header, 2.54mm, 10x1,
R/A, TH
TSW-110-08-T-S-
RA
Samtec
J3, J4 2 Receptacle, 50mil, 10x1, Gold,
R/A, TH
receptacle 10x1, 50mil 851-43-010-20-001
000
Mill-Max
J5, J6, J8, J9, J11,
J12, J13
7 Header, 2.54 mm, 2x1, Tin, TH Header, 2.54 mm, 2x1,
TH
TSW-102-07-T-S Samtec
J7 1 Header, 2.54 mm, 3x1, Tin, TH Header, 2.54 mm, 3x1,
TH
TSW-103-07-T-S Samtec
J10 1 Terminal Block, 5.08 mm, 2x1,
Brass, TH
2x1 5.08 mm Terminal
Block
ED120/2DS On-Shore
Technology
J15 1 Connector, Receptacle, USB
Micro B, R/A, SMT
Connector, Receptacle,
USB Micro B, R/A,
SMT
10118193-0001LF FCI
J101, J201 2 Receptacle, 2.54mm, 7x1, Gold,
TH
Receptacle, 2.54mm,
7x1, TH
PPPC071LFBN-
RC
Sullins Connector
Solutions
J301 1 Receptacle, 2.54mm, 10x1,
Gold, R/A, TH
Receptacle, 2.54mm,
10x1, TH
613010143121 Wurth Elektronik
J302, J303, J304,
J305, J306
5 Touchproof Jack, R/A, TH Touchproof Jack, R/A,
TH
8R004182801F PlasticsOne
www.ti.com Hardware Reference
SBAU370 – APRIL 2021
Submit Document Feedback
AFE4500 EVM User Guide 41
Copyright © 2021 Texas Instruments Incorporated
