Table A-1. Bill of Materials (continued)
Designator Quantity Value Description PackageReference PartNumber Manufacturer Alternate
PartNumber
Alternate
Manufacturer
L1, L2, L3, L4, L5,
L6, L7, L8
8 Inductor, Ferrite Bead, Ferrite,
0.2 A, 2.1 ohm, SMD
1x0.5mm MMZ1005S182ET0
00
TDK
L9 1 1uH Inductor, Shielded Drum Core,
Ferrite, 1 uH, 1.5 A, 0.065 ohm,
SMD
WE-TPC-T 744028001 Wurth Elektronik
L10 1 120 ohm Ferrite Bead, 120 ohm @ 100
MHz, 0.5 A, 0603
0603 BLM18AG121SN1
D
MuRata
PCB1 1 AFE4410/AFE4420 Sensor
Board
Used in PnP output
and some BOM reports
MHR041A Texas Instruments - -
R1, R3, R9, R10 4 49.9k RES, 49.9 k, 1%, 0.05 W, 0201 0201 RC0201FR-0749K
9L
Yageo America
R2, R4, R7, R8 4 10k RES SMD 10K OHM 0.1%
1/20W 0201
0201 ERA-1AEB103C Panasonic
R5, R6, R11, R12 4 100k RES, 100 k, 1%, 0.05 W, 0201 0201 RC0201FR-07100
KL
Yageo America
R13 1 20.0k RES, 20.0 k, 1%, 0.05 W, 0201 0201 CRCW020120K0F
KED
Vishay-Dale
R14 1 768k RES, 768 k, 1%, 0.05 W, 0201 0201 RC0201FR-07768
KL
Yageo America
R15 1 180k RES, 180 k, 1%, 0.05 W, 0201 0201 RC0201FR-07180
KL
Yageo America
R16, R28 2 1.10Meg RES, 1.10 M, 1%, 0.05 W, 0201 0201 RC0201FR-071M1
L
Yageo America
R17, R18, R21 3 RES SMD 0 OHM JUMPER
1/20W 0201
0201 (0603 Metric) RC0201JR-070RL Yageo
R19 1 470k RES, 470 k, 5%, 0.05 W, 0201 0201 RC0201JR-07470K
L
Yageo America
R20, R34 2 330k RES, 330 k, 1%, 0.05 W, 0201 0201 RC0201FR-07330
KL
Yageo America
R22, R23, R24,
R25, R27
5 100 RES, 100, 1%, 0.05 W, 0201 0201 ERJ-1GEF1000C Panasonic
R26 1 47.0k RES, 47.0 k, 1%, 0.05 W, 0201 0201 RC0201FR-0747K
L
Yageo America
R29, R30 2 22.0 RES, 22.0, 1%, 0.05 W, 0201 0201 RC0201FR-0722R
L
Yageo America
R31 1 1.40k RES, 1.40 k, 1%, 0.05 W, 0201 0201 RC0201FR-071K4
L
Yageo America
R32 1 33.0 RES, 33.0, 1%, 0.05 W, 0201 0201 RC0201FR-0733R
L
Yageo America
Hardware Reference www.ti.com
42 AFE4500 EVM User Guide SBAU370 – APRIL 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
