Table A-1. Bill of Materials (continued)
Designator Quantity Value Description PackageReference PartNumber Manufacturer Alternate
PartNumber
Alternate
Manufacturer
U9 1 500mA Low Dropout CMOS
Linear Regulators Stable with
Ceramic Output Capacitors, 6-
pin LLP, Pb-Free, 1000 Reel
NGG0006A LP38693SD-1.8/
NOPB
Texas Instruments
U10 1 500mA Low Dropout CMOS
Linear Regulators Stable with
Ceramic Output Capacitors, 6-
pin LLP, Pb-Free, 1000 Reel
NGG0006A LP38693SD-3.3/
NOPB
Texas Instruments
U11 1 16-Bit Ultra-Low-Power
Microcontroller, 128KB Flash,
8KB RAM, USB, 12Bit ADC,
2 USCIs, 32Bit HW MPY,
RGC0064B (VQFN-64)
RGC0064B MSP430F5528IRG
CT
Texas Instruments MSP430F5528IRG
CR
Texas Instruments
U12 1 Low-Capacitance + / - 15
kV ESD-Protection Array for
High-Speed Data Interfaces, 2
Channels, -40 to +85 degC, 5-pin
SOT (DRL), Green (RoHS & no
Sb/Br)
DRL0005A TPD2E001DRLR Texas Instruments
U13 1 SOIC8 ISO1640BDR Texas Instruments
U14 1 TCA9406 Dual Bidirectional 1-
MHz I2C-BUS and SMBus
Voltage Level-Translator, 1.65 to
3.6 V, -40 to 85 degC, 8-pin
DSBGA (YZP), Green (RoHS &
no Sb/Br)
YZP0008ADAD TCA9406YZPR Texas Instruments
U15 1 NAND Gate IC 1 Channel 4-
X2SON (0.8x0.8)
X2SON4 SN74LVC1G00DP
WR
Texas Instruments
U16 1 2-Bit Bidirectional Voltage-Level
Translator with Auto Direction
Sensing and +/-15-kV ESD
Protect, YZP0008ADAD, LARGE
T&R
YZP0008ADAD TXB0102YZPR Texas Instruments
Y1 1 CLOCK OSCILLATOR, 32.768
KHz, CMOS, 1.425 to 5.5V, SMD
3.2x2.5mm ECS-327KE-TR ECS Inc.
Y2 1 Crystal, 24 MHz, SMD 2x1.6mm ABM11-24.000MH
Z-D2X-T3
Abracon
Corporation
C101, C108, C109,
C114, C201, C208,
C211, C212
0 10pF CAP, CERM, 10 pF, 10 V,+/-
2.5%, C0G/NP0, 0402
0402 C0402C100C8GA
CTU
Kemet
C102, C107, C110,
C113, C202, C207,
C210, C213
0 100pF CAP, CERM, 100 pF, 50 V, +/-
1%, C0G/NP0, 0402
0402 04025A101FAT2A AVX
Hardware Reference www.ti.com
44 AFE4500 EVM User Guide SBAU370 – APRIL 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
To Next Page
