Table A-1. Bill of Materials (continued)
Designator Quantity Value Description PackageReference PartNumber Manufacturer Alternate
PartNumber
Alternate
Manufacturer
C103, C106, C111,
C112, C203, C206,
C209, C214
0 0.022uF CAP, CERM, 0.022 uF, 50 V, +/-
10%, C0G/NP0, 0402
0402 GCM155R71H223
KA55D
MuRata
C104, C204 0 1000pF CAP, CERM, 1000 pF, 50 V, +/-
1%, C0G/NP0, 0402
0402 GRM1555C1H102
FA01D
MuRata
C105, C205 0 0.22uF CAP, CERM, 0.22 µF, 16 V,+/-
10%, X7R, 0402
0402 CL05B224KO5NN
NC
Samsung Electro-
Mechanics
FID1, FID2, FID3,
FID4, FID5, FID6,
FID7, FID8, FID9,
FID10, FID11,
FID12, FID13,
FID14, FID15,
FID16, FID17,
FID18, FID19,
FID20, FID21,
FID22, FID23,
FID24
0 Fiducial mark. There is nothing to
buy or mount.
N/A N/A N/A
J14 0 Footprint for Tag-Connect
TC2050 cables, There is nothing
to buy or mount.
Footprint for TC2050
series of cables
TC2050-IDC-FP Tag-Connect
R201, R202, R203,
R204, R205, R206,
R207, R208, R209,
R210, R211, R212,
R213, R214
0 0 RES, 0, 0%, 0.2 W, AEC-Q200
Grade 0, 0402
0402 CRCW04020000Z
0EDHP
Vishay-Dale
TP1, TP2, TP3,
TP4, TP5, TP6,
TP7, TP8
0 TEST POINT. There is nothing to
buy or mount.
N/A N/A N/A
Note
Unless otherwise noted in the Alternate PartNumber and/or Alternate Manufacturer columns, all parts may be substituted with equivalents.
www.ti.com
Hardware Reference
SBAU370 – APRIL 2021
Submit Document Feedback
AFE4500 EVM User Guide 45
Copyright © 2021 Texas Instruments Incorporated
