VDDS_OSC
XTALOUT
t
sX
VDD_CORE (min.)
Time
Voltage
VSS
VDDS_OSC (min.)
VSS
VDD_CORE
AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com SPRS717H –OCTOBER 2011–REVISED MAY 2015
Table 6-3. OSC0 Crystal Circuit Characteristics
NAME DESCRIPTION MIN TYP MAX UNIT
C
pkg
Shunt capacitance of ZCE package 0.01 pF
package
ZCZ package 0.01 pF
P
xtal
The actual values of the ESR, ƒ
xtal
, and C
L
should be used to yield a P
xtal
= 0.5 ESR (2 π ƒ
xtal
typical crystal power dissipation value. Using the maximum values C
L
VDDS_OSC)
2
specified for ESR, ƒ
xtal
, and C
L
parameters yields a maximum power
dissipation value.
t
sX
Start-up time 1.5 ms
Figure 6-10. OSC0 Start-Up Time
