Complete stackup specifications are provided in Table 7-34.
Table 7-34. PCB Stackup Specifications
(1)
NO. PARAMETER MIN TYP MAX UNIT
1 PCB routing and plane layers 4
2 Signal routing layers 2
3 Full ground layers under LPDDR routing region 1
4 Number of ground plane cuts allowed within LPDDR routing region 0
5 Full VDDS_DDR power reference layers under LPDDR routing region 1
6 Number of layers between LPDDR routing layer and reference ground 0
plane
7 PCB routing feature size 4 mils
8 PCB trace width, w 4 mils
9 PCB BGA escape via pad size
(2)
18 20 mils
10 PCB BGA escape via hole size
(2)
10 mils
11 Single-ended impedance, Zo
(3)
50 75 Ω
12 Impedance control
(4)(5)
Zo-5 Zo Zo+5 Ω
(1) For the LPDDR device BGA pad size, see the LPDDR device manufacturer documentation.
(2) A 20-10 via may be used if enough power routing resources are available. An 18-10 via allows for more flexible power routing to the
AM335x device.
(3) Zo is the nominal singled-ended impedance selected for the PCB.
(4) This parameter specifies the AC characteristic impedance tolerance for each segment of a PCB signal trace relative to the chosen Zo
defined by the single-ended impedance parameter.
(5) Tighter impedance control is required to ensure flight time skew is minimal.
