Page #156 background imageLoading...
Page #156 background image
AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H OCTOBER 2011REVISED MAY 2015
www.ti.com
7.7.2.1.2.9 LPDDR Signal Termination
There is no specific need for adding terminations on the LPDDR interface. However, system designers
may evaluate the need for serial terminators for EMI and overshoot reduction. Placement of serial
terminations for DQS[x] and DQ[x] net class signals should be determined based on PCB analysis.
Placement of serial terminations for ADDR_CTRL net class signals should be close to the AM335x device.
Table 7-40 shows the specifications for the serial terminators in such cases.
Table 7-40. LPDDR Signal Terminations
NO. PARAMETER MIN TYP MAX UNIT
1 CK net class
(1)
0 22 Zo
(2)
Ω
2 ADDR_CTRL net class
(1)(3)(4)
0 22 Zo
(2)
Ω
3 DQS0, DQS1, DQ0, and DQ1 net classes 0 22 Zo
(2)
Ω
(1) Only series termination is permitted.
(2) Zo is the LPDDR PCB trace characteristic impedance.
(3) Series termination values larger than typical only recommended to address EMI issues.
(4) Series termination values should be uniform across net class.
156 Peripheral Information and Timings Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
