Table 7-116. UART IrDA—Signaling Rate and Pulse Duration—Transmit Mode
ELECTRICAL PULSE DURATION
SIGNALING RATE UNIT
MIN MAX
SIR
2.4 Kbps 78.1 78.1 µs
9.6 Kbps 19.5 19.5 µs
19.2 Kbps 9.75 9.75 µs
38.4 Kbps 4.87 4.87 µs
57.6 Kbps 3.25 3.25 µs
115.2 Kbps 1.62 1.62 µs
MIR
0.576 Mbps 414 419 ns
1.152 Mbps 206 211 ns
FIR
4 Mbps (single pulse) 123 128 ns
4 Mbps (double pulse) 248 253 ns
