Appendix A
DLPU030B–June 2015–Revised July 2015
Installing the DLP NIRscan Nano Software
A.1 DLP NIRscan Nano Software Installation
The NIRscan Nano software is broken into several packages:
• DLPNIRscanNanoGUI-1.0.3-windows-installer.exe
– This is the PC program that communicates with the DLP NIRscan Nano through USB.
– This program installs the PC GUI NIRscanNanoGUI.exe under the default directory: C:\Program
Files\Texas Instruments\NIRscanNanoGUI_1.0.2\Binaries
– It also install the sources under the default directory: C:\ti\NIRscanNanoGUI\Sources
• DLPNIRscanNanoSoftware-windows-installer.exe
– This program installs the Tiva binary firmware file under the default directory:
C:\ti\DLPNIRscanNanoSoftware_1.0.0\Binaries\NIRscanNano.bin
– It also installs the sources under the default directory:
C:\ti\DLPNIRscanNanoSoftware_1.0.0\Sources
– This installer includes the TI-RTOS 2.10.1.38 and the Device Firmware Update (DFU) drivers for
Tiva. The DFU drivers allow updating the Tiva firmware through USB. If your CCS installation
already has TI-RTOS 2.10.1.38, you can skip installing this TI-RTOS package.
• DLPSpectrumLibrary-1.0.0-windows-installer.exe
– This program installs the DLP Spectrum Library. This library code is shared with the PC GUI, Tiva
software, and iOS App. The source files are under the default directory:
C:\ti\DLPSpectrumLibrary_1.0.0\src.
• DLPR150PROM-1.0.0-windows-installer.exe
– This program installs the DLPC150 firmware binary (DLPR150PROM_1.0.0.img) under the default
directory: C:\ti\DLPR150PROM_1.0.0
To install the software, run these installer executables and follow the on-screen prompts.
