Chapter 1
DLPU030B–June 2015–Revised July 2015
DLP NIRscan Nano Overview
1.1 Introduction
The DLP® NIRscan Nano™ EVM is a complete evaluation module to design a high performance,
affordable near-infrared portable spectrometer. This flexible tool contains everything a designer needs to
start developing a DLP-based spectrometer right out of the box. DLP technology enables handheld
spectral analyzers for use in the food, pharmaceutical, oil and gas, medical, security, and other emerging
industries to deliver lab performance levels in the field. The EVM contains the DLP2010NIR digital
micromirror device, DLPC150 digital controller, and DLPA2005 integrated power management
components. This technology brings together a set of components providing an efficient and compelling
spectroscopy system solution for:
• Portable process analyzers
• Ultra-mobile spectrometer
The new DLP2010NIR DMD is optimized for operation at wavelengths between 700 and 2500 nm. The
DLP NIRscan Nano EVM is one possible implementation of this new DLP technology, operating from 900
to 1700 nm.
1.2 What is the DLP NIRscan Nano EVM?
The DLP NIRscan Nano EVM is a complete NIR spectrometer EVM using DLP technology. The EVM
package includes:
• Near-infrared optomechanical spectrometer engine optimized for 900 to 1700 nm wavelength range:
– Reflective illumination module with two integrated infrared lamps
– 1.69-mm × 0.25-mm input slit
– Collimating lenses
– 885-nm long wavepass filter
– Reflective diffraction grating
– Focusing lenses
– DLP2010NIR DMD (0.2-inch WVGA, 854 × 480 orthogonal pixel, NIR optimized)
– Collection optics
– 1-mm single-pixel InGaAs non-cooled detector
• Electronics subsystem with the electronics consisting of four boards:
– Microcontroller board
• Tiva TM4C1297 microprocessor for system control operating at 120 MHz
• 32MB SDRAM for pattern storage
• Power management with Lithium-polymer or Lithium-ion battery charging circuits using bq24250
• CC2564MODN Bluetooth Low Energy module for Bluetooth 4.0 connectivity
• USB micro connector for USB connectivity
• microSD card slot for external data storage
• HDC1000 humidity and temperature sensor
– DLP controller board
• DLPC150 DLP controller
• DLPA2005 integrated power management circuit for DMD and DLP controller supplies
8
DLP NIRscan Nano Overview DLPU030B–June 2015–Revised July 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated
