Appendix D
DLPU030B–June 2015–Revised July 2015
Required Tools to Compile NIRscan Nano GUI
D.1 NIRscan Nano GUI
The NIRscan Nano GUI requires Qt Framework and tools 5.4.1 or later, MinGW compiler 4.9.1, and the
DLP Spectrum Library. The Qt Framework and tools can be downloaded from the Qt website.
D.1.1 Compiling the DLP Spectrum Library
The DLP Spectrum Library includes a batch file to compile for the PC. To compile the DLP Spectrum
Library for the NIRscan Nano GUI, follow these steps:
1. Open MS-DOS window and change to the src directory of the DLP Spectrum Library:
C:/ti/DLPNIRNANO_SPECLIB/src
2. Execute the build-lib.bat file. This batch file requires the prior installation of MinGW or a GCC toolchain
in the Windows PC with their respective binaries added to the Windows PATH environment variable.
D.1.2 Compiling NIRscan Nano GUI
After compiling the DLP Spectrum Library, compile the NIRscan Nano GUI with the following steps:
1. Run Qt Creator.
2. In Qt Creator, click on "Open Project" button. Navigate to the directory where the NIRscanNanoGUI
sources were installed. The default installation directory is C:\ti\NIRscanNanoGUI\Sources. Open the
project file NirscanNanoGUI.pro
3. A dialog window will indicate that no user settings were found. Click the Yes button.
4. Click the Projects icon on the sidebar. Ensure that the Build settings are correct and that an existing
Build directory is set.
5. From the Build menu, select Build All.
53
DLPU030B–June 2015–Revised July 2015 Required Tools to Compile NIRscan Nano GUI
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated
