Appendix F
DLPU030B–June 2015–Revised July 2015
DLP NIRscan Nano Connectors
F.1 Battery Connector
The battery power (J6) connector of the microprocessor board requires the following 2-pin, 2-mm
connector part numbers:
• JST part number: PHR-2
• Digi-Key part number: 455-1165-ND
The corresponding connector terminal (crimp) part numbers are:
• JST part number: SPH-002T-P0.5L
• Digi-Key part number: 455-2148-1-ND
Table F-1. Battery Power Connector (Tiva J6)
DESCRIPTION PIN SUPPLY RANGE
Power positive 1 4.2 V
Ground 2 Ground
NOTE: The preferred connection to the battery may be a direct solder type or any low resistance
contact connection.
F.2 Battery Thermistor Connector
The battery thermistor connector (J7) of the microprocessor board requires the following 2-pin, 1-mm
connector part numbers:
• JST part number: SHR-02V-S-B
• Digi-Key part number: 455-1377-ND
The corresponding connector terminal (crimp) part numbers are:
• JST part number: SSH-003T-P0.2
• Digi-Key part number: 455-1561-1-ND
Table F-2. Battery Thermistor Connector (Tiva J7)
DESCRIPTION PIN SUPPLY RANGE
Power positive 1 4.9 V
Ground 2 Ground
F.3 Expansion Connector
The expansion connector (J3) of the microprocessor board requires the following 10-pin, 1-mm connector
part numbers:
• JST part number: SHR-10V-S-B
• Digi-Key part number: 455-1385-ND
55
