Additional Resources
www.ti.com
4.7 The Community
4.7.1 TI E2E Community
Search the forums at e2e.ti.com. If you cannot find an answer, post your question to the community.
4.7.2 Community at Large
Many online communities focus on the LaunchPad – for example, http://www.43oh.com. You can find
additional tools, resources, and support from these communities.
5 FAQs
Q: I can't get the backchannel UART to connect. What's wrong?
A: Check the following:
• Do the baud rate in the host's terminal application and the USCI_A0 settings match?
• Are the appropriate jumpers in place on the isolation jumper block?
• Probe on RXD and send data from the host; if you don't see data, it might be a problem on the host
side.
• Probe on TXD while sending data from the MSP430. If you don't see data, it might be a configuration
problem on the USCI_A0 module.
• Consider the use of the hardware flow control lines (especially for higher baud rates)
Q: So the onboard emulator is really open source? And I can build my own onboard emulator?
A: Yes! We encourage you to do so, using the design files.
Q: The MSP430 G2 LaunchPad had a socket, allowing me change the target device. Why doesn't
this LaunchPad use one?
A: This LaunchPad provides more functionality, and this means using a device with more pins. Sockets for
devices with this many pins are too expensive for the LaunchPad's target price.
36
MSP430FR5969 LaunchPad™ Development Kit (MSP
‑
EXP430FR5969) SLAU535B–February 2014–Revised July 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated
