J3
V+
J13
Debugger
JTAG
eZ-FET
J10
J12
External
VCC
GND
GND
J9
J2
Bypass
Use
Charge
J11
Super
Cap
External
J4
J5
VCC
GND
GND
J1
Current
MSP430FR5969
target and
BoosterPack
Target
MSP430FR5969
Device
Measure
Debug
Power
Domain
External
Power
Domain
Super Cap
Power
Domain
Target and
BoosterPack
Power
Domain
Legend
Hardware www.ti.com
2.4 Power
The board is designed to support five different power scenarios. The board can be powered by the eZ-
FET or JTAG debugger, external power, BoosterPack power, or standalone super cap power.
Figure 11. MSP430FR5969 LaunchPad Power Domain Block Diagram
16
MSP430FR5969 LaunchPad™ Development Kit (MSP ‑ EXP430FR5969) SLAU535B–February 2014–Revised July 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated
