8.24 I2C
The inter-integrated circuit interface (I
2
C) peripherals in these devices provide bidirectional data transfer with
other I2C devices on the bus and support the following key features:
7-bit and 10-bit addressing mode with multiple 7-bit target addresses
Multiple-controller transmitter or receiver mode
Target receiver or transmitter mode with configurable clock stretching
Support Standard-mode (Sm), with a bit rate up to 100 kbit/s
Support Fast-mode (Fm), with a bit rate up to 400 kbit/s
Support Fast-mode Plus (Fm+), with a bit rate up to 1 Mbit/s
Supported on open drain IOs (ODIO) and high-drive (HDIO) IOs only
Separated transmit and receive FIFOs support DMA data transfer
Support SMBus 3.0 with PEC, ARP, timeout detection and host support
Wakeup from low power mode on address match
Support analog and digital glitch filter for input signal glitch suppression
8-entry transmit and receive FIFOs
For more details, see the I2C chapter of the MSPM0 G-Series 80-MHz Microcontrollers Technical Reference
Manual.
8.25 SPI
The serial peripheral interface (SPI) peripherals in these devices support the following key features:
Support ULPCLK/2 bit rate and up to 32Mbits/s in both controller and peripheral mode
1
Configurable as a controller or a peripheral
Configurable chip select for both controller and peripheral
Programmable clock prescaler and bit rate
Programmable data frame size from 4 bits to 16 bits (controller mode) and 7 bits to 16 bit (peripheral mode)
Supports PACKEN feature that allows the packing of 2 16 bit FIFO entries into a 32-bit value to improve CPU
performance
Transmit and receive FIFOs (4 entries each with 16 bits per entry) supporting DMA data transfer
Supports TI mode, Motorola mode and National Microwire format
For more details, see the SPI chapter of the MSPM0 G-Series 80-MHz Microcontrollers Technical Reference
Manual.
8.26 CAN-FD
The controller area network (CAN) controller enables communication with a CAN2.0A, CAN2.0B, or CAN-FD bus
and is compliant to ISO 11898-1:2015 standard supporting upto 5Mbit/s bit rate. Key features of the CAN-FD
peripheral include:
Full support for 64-byte CAN-FD frames
Dedicated 1kB message SRAM with ECC
Configurable transmit FIFO, transmit queue and event FIFO (up to 32 elements)
Up to 32 dedicated transmit buffers and 64 dedicated receive buffers
Two configurable receive FIFOs (up to 64 elements each)
Up to 128 filter elements
Two interrupt lines
Power-down and wake-up support
Timestamp counter
For more details, see the CAN-FD chapter of the MSPM0 G-Series 80-MHz Microcontrollers Technical
Reference Manual.
1
Only SPI signals on HSIO pins support data rate > 16 Mbits/s; see the Pin Diagrams section for HSIO pins.
