Draw Operations 7-3
To display the DRAW DRAW menu, press
2
F
. What happens when you
select an item from this menu depends on whether or not a graph is displayed
when you access the menu, as described under each operation.
DRAW POINTS
1: CLRDRAW
Clears all drawn elements.
2: LINE(
Draws a line between two points.
3: HORIZONTAL
Draws a horizontal line.
4: VERTICAL
Draws a vertical line.
5: DRAWF
Draws a function.
6: SHADE_Y>
Shades an area.
7: SHADE_Y<
Shades an area.
8: SHADE(
Shades an area.
9: GRIDON
Turns the graph grid on.
0: GRIDOFF
Turns the graph grid off.
(See page 7
-
12 for an explanation of
CLRDRAW
.)
Because Draw operations draw on top of the graph of
currently selected functions, you may want to do one or more
of the following before drawing on a graph:
¦
Change the mode settings.
¦
Enter or edit functions in the
Y=
list.
¦
Select or deselect functions in the
Y=
list.
¦
Change Window variable values.
¦
Turn
STAT PLOTS
on or off.
¦
Clear existing drawings with
CLRDRAW
(page 7
-
12).
Draw operations can draw on
FUNC
and
PARAM
graphs. The
coordinates for all Draw instructions are always the
X-coordinate and Y-coordinate values of the display.
You can use most of the operations from the
DRAW DRAW
and
DRAW POINTS
menus to draw directly on a graph, using
the cursor to identify coordinates; or you can execute these
instructions from the Home screen or a program.
DRAW DRAW Menu
DRAW DRAW
Menu
Before Drawing
on a Graph
Drawing on a
Graph
To Next Page
