Implicit DSP/BIOS Instrumentation
3-30
You can rewrite this equation:
You can also express CPU load using instruction cycles rather than time
intervals:
3.6.1.1 Measuring the CPU Load
In a DSP/BIOS application, the CPU is doing work when any of the following
are occurring:
❏ hardware interrupts are serviced
❏ software interrupts and periodic functions are run
❏ task functions are run
❏ user functions are executed from the idle loop
❏ HST channels are transferring data to the host
❏ real-time analysis data is uploaded to the DSP/BIOS Analysis Tools
When the CPU is not performing any of those activities, it is going through the
idle loop, executing the IDL_cpuLoad function, and calling the other
DSP/BIOS IDL objects. In other words, the CPU idle time in a DSP/BIOS
application is the time that the CPU spends doing the routine in Example 3-3.
To measure the CPU load in a DSP/BIOS application over a time interval T, it
is sufficient to know how much time was spent going through the loop, shown
in Figure 3-3, and how much time was spent doing application work.
Example 3-3. The Idle Loop
Over a period of time T, a CPU with M MIPS (million instructions per second)
executes M x T instruction cycles. Of those instruction cycles, c
w
are spent
doing application work. The rest are spent executing the idle loop shown in
Example 3-3. If the number of instruction cycles required to execute this loop
once is l
1
, the total number of instruction cycles spent executing the loop is
CPUload
t
w
t
w
t
i
+
--------------
100×=
CPUloa d
c
w
c
w
c
i
+
----------------
100×=
’Idle_loop:
Perform IDL_cpuLoad
Perform all other IDL functions (user/system functions)
Goto IDL_loop’
