5. REMOTE ANALOG PROGRAMMING
5.1. INTRODUCTION
The rear panel connector J1 allows the user to program the power supply output voltage and current
limit with an analog device. J1 also provides monitoring signals for output voltage and output current.
The programming range and monitoring signals range can be selected between 0-5V or 0-10V using
the setup switch SW1. When the power supply is in Remote Analog programming, the serial
communication port is active and can be used to read the power supply parameters.
5.2. LOCAL /REMOTE ANALOG CONTROL
Contact 8 of J1 (Fig. 4-2, item 5) accepts TTL signal or Open-Short contact (referenced to J1-12) to
select between Local or Remote Analog programming of the output voltage and current limit.
In Local mode, the output voltage and current limit can be programmed via the front panel VOLTAGE
and CURRENT encoders or via the RS232/485 port. In Remote Analog mode, the output voltage and
current limit can be programmed by analog voltage or by programming resistors via J1 contacts 9 and
10 (refer to sec. 6.4 and 6.5). Refer to Table 6-1 for Local/Remote Analog control (J1-8) function and
Setup switch SW1-1, 2 setting.
Table 6-1: Local/Remote Analog control function
SW1-1,2 setting J1-8 function
Output voltage/
Current setting
Down (default) No effect Local
“0” or Short Remote Up
“1” or Open Local
5.3. LOCAL/REMOTE ANALOG INDICATION
Contact 21 of J1 (Fig. 4-2, item 5) is an open collector output that indicates if the power supply is in
Local mode or in Remote Analog mode. To use this output, connect a pull-up resistor to a voltage
source of 30Vdc maximum. Choose the pull-up resistor so that the sink current will be less than 5mA
when the output is in low state. Refer to Table 6-2 for J1-21 function.
Table 6-2: Local/Remote Analog indication
J1-8 SW1-1 SW1-2 J1-21 signal
Down Down Open
Down Up 0-0.6V
Up Down 0-0.6V
TTL “0” or short
Up Up 0-0.6V
TTL “1” or open Down or Up Down or Up Open
CAUTION
COM (J1-12), VPGM_RTN (J1-22) and IPGM_RTN (J1-23) terminals of
J1connect internally to the -Sense potential (-S). Do not connect these terminals
to any potential other than -Sense (-S), as it may damage the power supply.
