7.7.3 Initialization control commands
# Command Description
1
ADR n ADR is followed by address which can be 0 to 30 and is used to access the
power supply.
(Please set the standby time about 140ms before the ADR command.)
2
CLS Clear status. Sets FEVE and SEVE registers to zero (refer to section 7-8).
3
RST Reset command. Brings the power supply to a safe and known state:
Output voltage: zero, Remote: non-latched remote,
Output current: zero, Auto-start: Off,
Output: Off, OVP: maximum,
FOLD: Off, UVL: zero
The conditional registers (FLT and STAT) are updated, the other registers
are not changed.
4
RMT Sets the power supply to local or remote mode:
1. RMT 0 or RMT LOC, sets the power supply into Local mode.
2. RMT 1 or RMT REM, sets the unit into remote mode.
3. RMT 2 or RMT LLO, sets the unit into Local Lockout mode
(latched remote mode).
5
RMT?
Returns the Remote mode setting:
1.”LOC”-The unit is in Local mode.
2.”REM”-The unit is in Remote mode.
3.”LLO”-The unit is in Local Lockout (latched remote) mode.
7.7.4 ID control commands
# Command Description
1 IDN? Returns the power supply model identification as an ASCII string.
(Example: TEXIO, PU6-200)
2 REV? Returns the software version as an ASCII string.
3 SN? Returns the unit serial number. Up to 12 characters.
7.7.5 Output control commands
# Command Description
1
PV n Sets the output voltage value in Volts. The range of voltage value is
described in Table 7-3. The maximum number of characters is 12. See the
following examples for PV n format: PV 12, PV 012, PV 12.0, PV 012.00,
etc....
2
PV? Reads the output voltage setting. Returns the string “n” where “n” is the
exact string sent in the PV n command. When in Local mode, returns the
V/I CHK (front panel) settings in a 5 digits string.
3
MV? Reads the actual output voltage. Return 5 digits string.
Example: 60V supply sends 01.150, 15.012, 50.000, etc...
4
PC n Sets the output current value in Amperes. The range of current values is
described in Tables 7-4. The maximum number of characters is 12. See
the following examples for PC n format: PC 10, PC 10.0, PC 010.00, etc...
5
PC? Reads the output current setting. Returns the string “n” where “n” is the
exact string sent in the PC n command. When in Local mode, returns the
V/I CHK (front panel) settings in a 5 digits string.
6
MC? Reads the actual output current. Returns 5 digits string.
Example: 90A supply sends 90.000.
7
OUT n Turns the output to ON or OFF. Recover from Safe-Start, OVP or FLD fault.
OUT 1(or OUT ON)-Turn On.
OUT 0(or OUT OFF)-Turn Off.
