Ultra Tugger
®
10 Cable Puller and Pulling Packages
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
112
1 Bearing housing .................................... 1
2 Bearing, 85 mm x 45 mm x 19 mm
ball ........................................................1
3 Bearing, Torrington BH-3316 ................ 1
4 Inner race, Torrington IR-2824 .............. 1
5 Bearing, Torrington B-128.....................8
6 Shaft, 3rd reduction ..............................4
7 Thrust washer, .760 x 1.25 x .02 .........14
8 Gear, 3rd reduction planet ....................4
9 Plate, output hub ..................................1
10 Hub, output ........................................... 1
11 Hub, 2nd reduction ............................... 1
12 Gear, 3rd reduction sun ........................1
13 Shaft, 2nd reduction .............................3
14 Gear, 2nd reduction planet ...................3
15 Bearing, Torrington B-1212...................3
16 Plate, 2nd reduction hub ......................1
17 Gear, 2nd reduction sun .......................1
18 Hub, 1st reduction ................................1
19 Plate, 1st reduction hub ........................1
20 Shaft, planet ..........................................2
21 Washer, thrust ....................................... 4
22 Gear, 1st reduction planet.....................2
23 Plate, planetary input ............................ 1
24 Bearing, 40 mm x 17 mm x 12 mm
ball ........................................................1
25 Shaft, 1st reduction ..............................1
26 Gear, high driven ...................................1
27 Gear, low driven ....................................1
28 Clutch, Torrington RCB-081214 ...........2
29 Clutch, Torrington RCB-101416 ...........1
30 52046741 Housing, intermediate ...........................1
31 Plate, motor mount ............................... 1
33 Gear, reversing ...................................... 1
34 Shaft, idler .............................................1
35 Bearing, Torrington BH-68 .................... 2
36 Bearing, Torrington BH-88 .................... 1
37 Gear, 1st reduction sun .........................1
38 Retaining ring, 25 mm ext. ....................2
39 Bearing, Torrington BH-810 .................. 2
40 52046739 Gear, ring ..............................................1
41 Bearing, Torrington B-46.......................6
42 Washer, thrust ....................................... 3
Key Part No. Description Qty Key Part No. Description Qty
43 52026672 Shaft, center .........................................1
44 Seal, grease ..........................................1
45 Dowel pin, 1/4 x 1.25 ............................ 6
46 Dowel pin, 5/16 x .625 .......................... 9
47 Screw, cap, #8-32 socket at head ......4
48 Screw, cap, #8-32 socket at head ......7
49 Dowel pin, 1/4 x .50 .............................. 3
50 Screw, 5/16-18 x 1.50 button head ......2
51 Screw, 5/16-18 UNC x 3.25
button head...........................................2
52 Screw, 1/4-20 UNC x 1.00
socket head ..........................................4
53 Screw, 1/4-28 UNF x 2.00
socket head ..........................................6
54 Screw, 1/4-28 UNF x 1.00
socket head ..........................................6
55 Key, #404 Woodruff ..............................1
56 52058418 Motor mounting plate ...........................2
57 Commutator brush ................................2
58 52061592 Armature assembly (120 V) ...................1
52064051 Armature assembly (230 V) ................... 1
59 52061593 Magnet housing ....................................1
60 52061594 End bell assembly ................................. 1
Kits
52060769 Reversing gear assembly
[includes 33, 34]
52060770 Output housing assembly
[includes 1, 3, 44]
52060851 Output shaft assembly
[includes 2, 4-6, 7 (8), 8-10, 41 (2), 46 (4)]
52060852 2nd reduction planet assembly
[includes 7 (6), 11-16, 38 (1), 41 (2), 46 (3)]
52060853 1st reduction planet assembly
[includes 17-22, 38 (1), 39, 41 (2), 46 (2)]
52060854 Planet input housing assembly
[includes 23, 35]
52060855 Two speed gear shaft assembly
[includes 24-27, 28 (1), 29, 37, 55]
52060856 Motor mount housing assembly
[includes 28 (1), 31, 36]
52060857 Seal and thrust washer kit
[includes 7, 21, 42, 44]
52060858 Hardware kit
[includes 45-55]
52060859 Commutator brush kit
[includes 57]
Parts List—Gearmotor
Lista de piezas—Motor de engranajes
Nomenclature des pièces—Moteur à engrenages
52046719 (120 V), 52062708 (230 V)
