Ultra Tugger
®
10 Cable Puller and Pulling Packages
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
114
1 52058623 Carriage weldment ................................1
2 52058608 Boom mount weldment ........................1
3 52058277 Elbow/nose weldment ..........................2
4 Pivot weldment .....................................2
5 00562 Elbow assembly .................................... 2
6 Sheave unit, 9" ......................................2
7 00561 Boom, 3' ...............................................1
8 00560 Boom, 4' ...............................................1
9 52058618 Worm.....................................................1
10 52061270 Sheave shaft kit (includes 10A, 10B) ....2
10A Shaft......................................................2
10B Roll pin, 3/16 x 1.50 .............................. 4
11 00471 Coupling hanger kit
(includes 11A–11F)................................1
11A Hanger weldment, short .......................1
11B Hanger weldment, long .........................1
11C Hairpin, cotter .......................................6
11D Lanyard .................................................3
11E Screw, 5/16-18 x 1.50 hex head ........... 4
11F Nut, 5/16-18 ange ............................... 4
12 52061273 Pivot shaft kit (includes 12A–12C) ........1
12A Shaft, main pivot ................................... 1
12B Ring, retaining ....................................... 2
12C Spacer, mount .......................................1
13 52061274 Idler wheel kit (includes 13A–13D) ........1
13A Wheel unit, idler ....................................1
13B Shaft......................................................1
13C Roll pin, 3/16 x 1.50 .............................. 1
13D Hairpin, cotter .......................................1
14 52061275 Bearing kit (includes 14A–14C) ............. 1
14A Race, bearing–thrust .............................2
14B Bearing, thrust needle ...........................1
14C Bearing, bronze .....................................2
15 52061276 Bearing block set
(includes 15A–15D) ...............................1
15A Block, upper bearing ............................1
15B Block, lower bearing .............................1
15C Screw, 5/16-18 x 3.25 hex head ........... 4
15D Nut, 5/16-18 ange ............................... 4
16 52061277 Guard kit (includes 16A, 16B) ...............1
16A Guard, gear ........................................... 1
16B Guard, worm .........................................2
17 52061278 Swivel caster kit (includes 17A–17C) ....2
17A Caster ...................................................1
17B Screw, 3/8-16 x 1.00 hex head ............. 4
17C Nut, 3/8-16 hex lock .............................4
18 52068651 Wheel kit (includes 18A, 18B) ...............1
18A Wheel ....................................................2
18B Ring, retaining ....................................... 3
19 52061280 Elbow detent pin kit
(includes 19A–19E) ...............................2
19A Sleeve, long detent ...............................1
19B Detent, long ..........................................2
19C Grip, detent ........................................... 4
19D Roll pin, 1/4 x 3.00 ................................ 2
19E Spring, detent .......................................1
20 52061281 Boom detent pin kit
(includes 20A–20C) ...............................3
20A Plunger ..................................................2
20B Ring, pull ............................................... 2
20C Spring ...................................................2
21 52060823 Transport handle kit
(includes 21A, 21B) ............................... 1
21A Push handle weldment .........................1
21B Screw, 5/16-18 x .625
socket head cap ...................................2
22 52061283 Crank handle kit (includes 22A, 22B) .... 1
22A Crank ....................................................1
22B Nut, 1/2-20 hex ..................................... 1
23 00563 2" slip-in conduit adapter .....................1
00564 2-1/2" slip-in conduit adapter ...............1
00565 3" slip-in conduit adapter .....................1
00566 3-1/2" slip-in conduit adapter ...............1
00567 4" slip-in conduit adapter .....................1
00610 5" slip-in conduit adapter .....................1
00583 2" screw-on conduit adapter ................1
00584 2-1/2" screw-on conduit adapter .........1
00585 3" screw-on conduit adapter ................1
00586 3-1/2" screw-on conduit adapter .........1
00587 4" screw-on conduit adapter ................1
Decal
Decal, warning ......................................3
Key Part No. Description Qty Key Part No. Description Qty
Parts List—Mobile Carriage and Boom
Lista de piezas—Carro móvil y brazo
Nomenclature des pièces—Chariot mobile et flèche
