16
5.6 Grounding connection
Please make sure the grounding terminal connect to the Grounding Bar.
• The grounding cable should have a diameter of not less than 4 mm² and be as close as possible
to the grounding point.
5.7 Active Equilibrium Function (Optional)
qualification Data specification
Balance current 0.5~1A
Balance mode Active equilibrium
Balance on condition Reach the user-defined opening voltage and differential pressure
Minimum voltage of single unit ≥ 3.2V (factory default) and
equalizing opening differential pressure: ≥50mV (factory default)
Balance closing condition Closing voltage and differential pressure reaching the user-defined
setting
Minimum voltage of single unit
＜
3.2V (factory default) and
equalizing differential pressure:
＜
50mV (factory default)
Working power
consumption
<11mA
Sleep current 300uA
working temperature
-20℃～60℃
Data Monitoring Bluetooth APP
Active Balance
Power
