any faults or incorrect displays and take corrective action if necessary.
4. Check all terminals for signs of corrosion, insulation damage, high temperatures or
burning/discolouration and tighten terminal screws.
5. Check for dirt, nesting insects and corrosion, clean anti insects net as required. 6. If the lightning
arrester has failed, replace the failed arrester in time to prevent lightning damage to the inverter or
other equipment of the user.
Make sure that the product is disconnected from all power sources and that the capacitors are fully
discharged before carrying out any checks or operations to avoid the risk of electric shock.
The Company shall not be liable for damage caused by:
1. Damage caused by improper use or use in a wrong location.
2. Photovoltaic modules with an open circuit voltage exceeding the maximum permissible voltage.
3. Damage caused by the operating temperature exceeding the restricted operating temperature
range
4. Dismantling and repair of the inverter by unauthorised persons.
5. Damage caused by force majeure: damage during transport or handling of the product.
10. Datasheet
MODEL
TEZE-AO-MB51400-AC380V-
10KW
TEZE-AO-MB51300-AC380V-
10KW
BATTERY TECHNICAL SPECIFICATION
Battery model TEZE-MB51400-200A-HWB TEZE-MB51300-200A-HWB
Number of batteries 1
Battery Energy 20.48kWh 15.36kWh
Battery Capacity 400AH 300AH
Weight
Dimension L× D× H (mm)
Battery Type LiFePO4
Battery Rated Voltage 51.2V
Battery Working Voltage Range
44.8 ～ 57.6V
Maximum Charging Current 200A
Maximum Discharging Current 200A
DOD 80%
Designed Life-span
>6000 Cycles @ 0.2C/25℃ Charging/Discharging at 80%DOD, Until
80% Capacity.
INVERTER TECHNICAL SPECIFICATION
Inverter model ASF48100SH3
PV CHARGE
Solar Charge Type MPPT
Maximum Iutput Power 7500W/7500W
PV Charging Current Range 22A+22A
PV Operating Voltage Range 800Vdc/800Vdc
MPPT Voltage Range 200-650Vdc
AC CHARGE
Frequency Range 50/60Hz
Input Voltage Range phase voltage 170~280V, line voltage 305~485V
Bypass Overload Current 63A
