7.3 Battery Communication Interface
7.3.1 LED Indicator
Four green capacity indicators, a red alarm indicator, a green running indicator and a switch indicator.
7.3.2 SOC capacity indicator
Condition
Charge
Discharge
Capacity indicator
lamp
L1
L2
L3
L4
L1
L2
L3
L4
power
（%）
0~25%
Flash 2
OFF
OFF
OFF
ON
OFF
OFF
OFF
25~50%
ON
Flash 2
OFF
OFF
ON
ON
OFF
OFF
50~75%
ON
ON
Flash 2
OFF
ON
ON
ON
OFF
75~100~
ON
ON
ON
Flash 2
ON
ON
ON
ON
Running indicator
light
ON
Flash 3
