AS 680/682
Subsystem Description Description, Operation and Maintenance
ADS−B
2−26 Ed. 10.07
Fig. 2−30 Detailed BITE Status display on RCMS (example)
2.4.2 Technical Situation Display (TSD)
See Figs. 2−31, 2−32.
The Remote Control and Monitoring System platform is also used as a simple Technical Situation Dis-
play (TSD) to display in real time the ADS−B traffic situation as acquired by a selected Ground Station.
Detailed
Target View
Map View
(Situation
Display)
Statusbar
Titlebar
Menubar
Toolbar
Fig. 2−31 ADS−B Technical Situation Display (example)
