AS 680/682
Installation and Setup Description, Operation and Maintenance
ADS−B
3−6 Ed. 10.07
SPU subrack, rear
DC−Power
local supply
Equipped with DC/DC−converter
AC−Power
local supply
Equipped with AC/DC−converter (option)
Mains switch AC
AC, 0.8AT/250V (2x)
Mains fuse
SPU subrack, rear
18...36 VDC
VAC 85V...264V
0
I
nom. 24 VDC
mains
nom. 230 VAC
6.3AT/250V (2x)
DC supply fuse
1)
1)
1)
1)
1) Provided by customer
PE PE
1)
1)
plus (+)
minus (−)
Fig. 3−10 ADS−B Ground Station AS 680, SPU, power connection rear side
Keyboard *
Mouse*
Monitor 2
Eth 0 Eth 1
Dual VGA
RCMS PC
Monitor 1
RS232
VGAint
USB
Parallel
VGA 1
VGA 2
4x
Mains sockets
230VAC
Mains 230 VAC
230VAC
local supply
ADS−B LAN
230VAC
230 VAC
TSD
TSC
rear view
rear view
rear view
19" TFT
19" TFT
example HP
to/from
Audio
* optional PS/2 connection
PS/2
1)
1)
1)
1)
1) Provided by customer
VGA cable,
Power cable
Power cable
Power cable
dual
Fig. 3−11 RCMS, system cabling
