THERMACUT EX-TRAFIRE 45SD - Page 17

EX-TRAFIRE
®
45SD
Operator Manual, Revision T-5 2-17
3~
f
1
f
2
1~
f
1
f
2
Symbol Description Symbol Description
GAS
Indicates flow of the gas�
Gas pressure fault�
Cutting mode
Direct Current (DC) power
The power supply is working�
Gouging mode
Indicates pressing of torch
trigger or connection of pins
3, 4 in the CNC connector�
Indicates arc transfer
An inverter-based power
supply - 1-phase
An inverter-based power
supply - 3-phase
The torch type
PARAMETERS:
Meters
Volts
Ampers
3~
f
1
f
2
1~
f
1
f
2
