EX-TRAFIRE
®
45SD
Operator Manual, Revision T-5 3-25
5� Torch connection – 2nd step – put TCS plug into the TCS socket�
The torch TCS plug must be locked in the TCS socket properly with the key nose�
6� Torch connection – proper position of the TCS plug in the TCS socket�
WARNING
FHT-EX
®
45TTH, TTM torches are only for use with
EX-TRAFIRE
®
45HD and EX-TRAFIRE
®
45SD power supplies�
TCS key nose
