EX-TRAFIRE
®
45SD
Operator Manual, Revision T-5 4-49
Mechanized Cutting Charts
30 A Cutting, Shielded Configuration
Notes:
* Cut capacity speeds are not necessarily maximum speeds�
They are the speeds that must be achieved to be rated at that
thickness�
** Maximum cut speeds are the results of intensive laboratory
testing�
Actual cutting speeds may vary based on different cutting
applications�
Cut charts are a guide for mechanized cutting, individual
systems can be “fine tuned” to achieve optimum cut quality�
*** Unshielded configuration
When using unshielded consumables, adjust the torch to
work height manually or adjust the Arc Voltage Control (AVC)
settings to produce the desired cut quality�
EX-2-401-201
EX-2-404-201
EX-2-409-201
EX-2-415-201
EX-2-421-201
***
EX-2-415-202
EX-2-421-201
EX-2-423-211
EX-2-428-011
