CUTMASTER 152
Manual 0-4987 2-3 INTRODUCTION
2.05 Input Wiring Specifications
CutMaster 152 Power Supply Input Cable Wiring Requirements
Input
voltage
Freq Power
Input
Suggested Sizes
Volts Hz kVA I max I eff Fuse
(amps)
FlexibleCord
(Min.AWG)
1 Phase 208 60 26.2 126 98 150 4 Type W
230 60 27.6 118 95 125 4 Type W
460 60 35 76 68 100 4
3 Phase 208 60 21.6 60 55 60 4
230 60 22.3 56 50 60 4
380 50 23 35 32 40 8
400 50 23.6 34 31 40 8
460 60 29.5 37 33 40 8
600 60 29.0 28 25 30 10
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
NOTE
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
The suggested sizes are based on flexible power cable with power plug installations. For hard-wired installations
refer to local or national codes.
I
1
max is taken at TDC rated minimum duty cycle.
I
1
eff is taken at TDC 100% rated duty cycle.
