cutmaster 82
Manual 0-4980 6-1 PARTS LIST
SECTION 6:
PARTS LISTS
6.01 Introduction
A. Parts List Breakdown
The parts list provide a breakdown of all replaceable components. The parts lists are arranged as follows:
Section 6.03 Complete Power Supply Replacement
Section 6.04 Replacement Parts
Section 6.05 Options and Accessories
Section 6.06 Left Side Replacement Parts
Section 6.07 Right Side Replacement Parts
Section 6.08 Options and Accessories
Section 6.09 Replacement Parts for Hand Torch
Section 6.10 Replacement Parts - for Mechanized Torches with Unshielded Leads
Section 6.11 Torch Consumable Parts Manual and Mechanized Torches
NOTE
Parts listed without item numbers are not shown, but may be ordered by the catalog number shown.
B. Returns
If a product must be returned for service, contact your distributor. Materials returned without proper authoriza-
tion will not be accepted.
6.02 Ordering Information
Order replacement parts by catalog number and complete description of the part or assembly, as listed in the parts
list for each type item. Also include the model and serial number of the power supply. Address all inquiries to
your authorized distributor.
6.03 Power Supply Replacement
The following items are included with the replacement power supply: work cable & clamp, input power cable, gas
pressure regulator / filter, and operating manual.
Qty Description Catalog #
1 CutMaster
82 Power Supply
208/230 - 460VAC, Single or 3 Phase, 60Hz,
with input power cable and plug 3-1130-1
460VAC, Single or 3 Phase, 60Hz,
with input power cable 3-1130-2
600VAC, 3 Phase, 60Hz,
with input power cable 3-1130-5
