OPERATION 4T-30 Manual 0-4989
Aluminum
100A
Air Plasma / Air Shield
Deector
Standard Shield Cup
Maximum Life Shield Cup
Tip Starter Cartridge Electrode
9-8243
9-8218
9-8237
9-8212 9-8213 9-8215
Material
Thickness
Gas Pressure
(Air)
Arc Voltage
Torch
Working
Height
Travel Speed
Initial
Piercing
Height
Pierce Delay
Kerf Width
@ Rec.
Speed
(GA)
(in) inch
PSI
(torch lead
length)
Volts
(in)
(ipm) (in) (sec) (in)
1/4 0.250
75 (25')
75 (50')
110 0.19 100 0.20
0.00
0.09
3/8 0.375
124 0.19 65 0.20
0.20
0.10
1/2 0.500
128 0.19 45 0.20
0.30
0.11
5/8 0.625
132 0.19 35 0.20
0.50
0.11
3/4 0.750
135 0.19 20 0.20 2.00 0.13
1 1.000
140 0.19 10 Edge Start 0.13
Material
Thickness
Gas Pressure
(Air)
Arc Voltage
Torch
Working
Height
Travel Speed
Initial
Piercing
Height
Pierce Delay
Kerf Width
@ Rec.
Speed
(mm)
Bar
(torch lead
length)
Volts (mm) (mm/min) (mm) (sec) (mm)
6
5.2 (7.6m)
5.2 (15.2m)
109
4.8
2630 5.1 0.00 2.3
8 117 4.8 2080 5.1 0.10 2.5
10 125
4.8
1575
5.1
0.20 2.7
12 127 4.8 1255 5.1 0.30 2.7
15 131
4.8
960
5.1 0.50
2.8
20 136
4.8
470
6.0 2.00
3.3
25 140
4.8
270
Edge Start
3.4
BOLD TYPE indicates maximum piercing parameters. BOLD ITALIC indicates edge starts only.
