Thermal Dynamics CUTMASTER A80 - Page 65

CUMASTER A80, A120
Manual 0-5119 4T-29 OPERATION
Stainless Steel
60A
Air Plasma / Air Shield
Shield Cap Maximum Life Shield Cup Tip Starter Cartridge Electrode
9-8238 9-8237 9-8210 9-8213 9-8232
Material
Thickness
Gas Pressure
(Air)
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
Kerf Width
@ Rec.
Speed
(GA)
(in) inch
PSI
(torch lead length)
Volts
(in)
(ipm) (in) (sec) (in)
16
0.063
85 (25')
90 (50')
110 0.13 165 0.20 0.00 0.06
14
0.078 116 0.13 155 0.20 0.10 0.07
11
0.125 118 0.13 125 0.20 0.10 0.07
10
0.141 126 0.13 80 0.20 0.10 0.09
3/16 0.188 125 0.13 75 0.20 0.20 0.09
1/4 0.250 127 0.13 60 0.20 0.30 0.08
3/8 0.375 134 0.13 28 0.20 0.50 0.08
1/2 0.500 136 0.19 17 0.25 0.75 0.09
5/8 0.625 131 0.13 14 Edge Start 0.08
3/4 0.750 142 0.19 10 Edge Start 0.11
Material
Thickness
Gas Pressure
(Air)
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
Kerf Width
@ Rec.
Speed
(mm)
Bar
(torch lead length)
Volts (mm) (mm/min) (mm) (sec) (mm)
1
5.9 (7.6m)
6.2 (15.2m)
101
3.3
4590 5.1 0.00 1.2
2
116 3.3 3925 5.1 0.10 1.7
3
118 3.3 3285 5.1 0.10 1.7
4
126 3.3 1985 5.1 0.20 2.2
5
125 3.3 1850 5.1 0.20 2.1
6
127 3.3 1605 5.1 0.30 2.1
8
131 3.3 1100 5.1 0.40 2.1
10
134 3.3 670 5.1 0.50 2.1
12
136 4.8 490 6.4 0.90 2.2
15
132 3.3 375 Edge Start 2.6
20
144
4.8
230 Edge Start 2.5
BOLD TYPE indicates maximum piercing parameters. BOLD ITALIC indicates edge starts only.
