PARTS LISTS 6-6 Manual 0-2815
6.07 Torch Spare Parts Kits
A. For Automated Pak Master 75XL Plus Applications
Qty Description Catalog #
VIP Spare Parts Kit Includes: 5-3511
20 Electrode (SureLok), MaximumLife™ 9-8407
40 Tip, Cutting, Air/N2, 60 Amp (0.049" Orifice) 9-7726
2 Gas Distributor 8-7501
1 Standard Shield Cup 8-7500
1 Shield Cup, Copper 8-7496
5 O-Ring 8-0532
3 Canted Coil Spring 9-7501
B. For CE Automated Pak Master 75XL Plus Applications
Qty Description Catalog #
VIP Spare Parts Kit Includes: 5-7615
20 Electrode (SureLok), General Purpose 9-8402
40 Tip, Cutting, Air/N2, 60 Amp (0.049" Orifice) 9-7726
2 Gas Distributor 8-7501
1 Standard Shield Cup 8-7500
1 Shield Cup, Copper 8-7496
5 O-Ring 8-0532
3 Canted Coil Spring 9-7501
C. For Automated Pak Master 100XL Plus Applications
Qty Description Catalog #
VIP Spare Parts Kit Includes: 5-3513
20 Electrode (SureLok), MaximumLife™ 9-8407
40 Tip, Cutting, Air/N2, 80 Amp (0.055" Orifice) 9-7728
2 Gas Distributor 8-7501
1 Standard Shield Cup 8-7500
1 Shield Cup, Copper 8-7496
3 Canted Coil Spring 9-7501
5 O-Ring 8-0532
D. For CE Automated Pak Master 100XL Plus Applications
Qty Description Catalog #
VIP Spare Parts Kit Includes: 5-7614
20 Electrode (SureLok), General Purpose 9-8402
40 Tip, Cutting, Air/N2, 80 Amp (0.055" Orifice) 9-7728
2 Gas Distributor 8-7501
1 Standard Shield Cup 8-7500
1 Shield Cup, Copper 8-7496
3 Canted Coil Spring 9-7501
5 O-Ring 8-0532
