MP-3000 Controller
82
CSR & Function Test Procedure
LED
Display
(Test No.)
LCD Display
(Shows Approx. Amps for
460V, 60 Hz Unit)
Test Description
Possible
Alarms
Duration
(Time)
F1.00
Display Test
Activated
0.1 A 0.0 A 0.1 A
Event Log for Function Test begins.
All alarms are turned off.
Alarm list is cleared.
All lights and bars in display turn on.
None 10 Seconds
F1.01
Sensor Test
Activated
0.1 A 0.0 A 0.1 A
All sensors must have values within their
measuring range.
00, 01, 02,
03, 04, 05,
28, 31, 32,
33, 34, 35,
97, 98, 112
2 Seconds
F1.02
Evaporator Fan Low
Activated
1.1 A 1.0 A 1.1 A
Amp draw is measured and compared to
voltage and frequency.
• CSR40 :
1.0 Amps approx. at 50 Hz,
1.0 Amps approx. at 60 Hz
• CSR20SL and CSR40SL:
1.5 Amps approx. at 50 Hz
1.6 Amps approx. at 60 Hz
14, 15 10 Seconds
F1.03
Evaporator Fan High
Activated
2.4 A 2.3 A 2.4 A
Amp draw is measured and compared to
voltage and frequency:
• CSR40:
2.1 Amps approx. at 50 Hz,
2.5 Amps approx. at 60 Hz
• CSR20SL and CSR40SL:
2.8 Amps approx. at 50 Hz
2.8 Amps approx. at 60 Hz
12, 13 10 Seconds
F1.04
Condenser Fan
Activated
0.8 A 0.7 A 0.8 A
Amp draw is measured and compared to
voltage and frequency: 0.8 Amps
Maximum.
16, 17 10 Seconds
F1.05
Reverse Phase
Activated
0.8 A 0.7 A 0.8 A
Condenser fan stops. Reverse phase
selector relay is energized and
condenser motor is started in reverse for
2 seconds. Amp draw difference
between correct and wrong motor
rotation must be less than 0.2 amps.
58 30 Seconds
F1.06
Compressor Test
Activated
7.1 A 7.0 A 7.1 A
With condenser fan on and compressor
on, compressor is operated at 25%
capacity. Amp draw is measured and
compared to voltage. Evaporator
temperature and condenser coil
temperature are measured and stored.
NOTE: If the condenser
temperature is below 15 C (59 F),
the condenser fan remains off for
this test.
06, 0, 31 14 Seconds
