Thermo King CSR Series User Manual

MP-3000 Controller
85
P1.05
Evaporator Fan High
Activated
2.7 A 2.6 A 2.7 A
Condenser fan and compressor are
turned off. With evaporator fan on high
speed, Amp draw is measured and
compared to voltage and frequency:
• CSR40:
2.2 Amps approx. at 50 Hz,
2.6 Amps approx. at 60 Hz
• CSR20SL and CSR40SL:
2.7 Amps approx. at 50 Hz,
3.2 Amps approx. at 60 Hz
Evaporator fan high speed amperes are
recorded in PTI log.
12, 13 10 Seconds
P1.06
Probe Test
Activated
2.7 A 2.6 A 2.7 A
Evaporator fans operate on high speed
for 3 minutes. Then probe test runs until
temperature difference between sensors
stops increasing. Maximum temperature
difference allowed:
• Return/Evaporator: 1.5 C (2.7 F);
return air sensor temperature must be
0.5 C (1.0 F) above evaporator sensor
temperature
• Return/Supply: 0.8 C (1.4 F); return air
sensor temperature must be 0.5 C (1.0
F) above supply air temperature
• LH Supply/RH Supply (if equipped): 0.5
C (0.9 F)
52
3 Minutes
Minimum
to
13 Minutes
Maximum
P1.07
Condenser Fan
Activated
0.8 A 0.7 A 0.8 A
Condenser fan is turned on.
Amp draw is measured and compared to
voltage and frequency: 1.2 Amps
Maximum. Condenser fan amperes are
recorded in PTI log.
16, 17 10 Seconds
P1.08
Reverse Phase
Activated
0.8 A 0.7 A 0.8 A
Condenser fan stops. Reverse phase
selector relay is energized and condenser
motor is started in reverse for 2 seconds.
Amp draw difference between correct and
wrong motor rotation must be less than
0.2 amps.
58 30 Seconds
P1.09
Compressor Test
Activated
7.1 A 7.0 A 7.1 A
With condenser fan on and compressor
on, compressor is operated at 25%
capacity. Amp draw is measured and
compared to voltage. Evaporator
temperature and condenser coil
temperature are measured and recorded
with condenser fan amperes in PTI log.
06, 07 14 Seconds
P1.10
Injection Valve Test
Activated
7.6 A 7.5 A 7.6 A
Condenser fan and compressor remain
on. Liquid injection valve is turned on.
Amp draw is measured and verified to be
a minimum of 0.2 amps higher that test
P1.09.
29 10 seconds
CSR Pre-trip (PTI) Test Procedure (Continued)
LED
Display
(Test No.)
LCD Display
(Shows Approx. Amps for
460V, 60 Hz Unit)
Test Description
Possible
Alarms
Duration
(Time)
