Z-dimensions
The figure below illustrates the position of the light
beam in the spectrophotometer.
The specifications for the sample compartment,
including the dimensions of the beam are:
• Z-dimension
• Square cuvettes/Test tubes 8.5mm
• Beam size 2mm (wide) x 7mm (high)
