•“1040Smallbottomcover”onpage74
•“1050Opticaldriveoroptical-drivebaybezel”onpage75
•“1070Harddiskdriveassemblyorsolid-statedriveassembly”onpage77
•“1080WirelessLANcard”onpage79
•“1090Coin-cellbattery”onpage81
•“1110Keyboard”onpage81
•“1120Keyboardbezelassembly”onpage83
•“1130Systemboardandthermalfan”onpage86
•“1140dc-in/USB-connectorboardwithcable”onpage91
RemovalstepsoftheLCDunit
Note:Thecomputerthatyouareservicingmightbedifferentfromtheoneinthefollowingillustrations.
Instep1,releasethewirelessantennacablesfromthecableguides.
1
1
1
1
1
1
1
1
Chapter9.RemovingorreplacingaFRU95
