Removalstepsoftheaudioconnectorcardwithcable
Note:Thesystemboardofthecomputerthatyouareservicingmightbedifferentfromtheoneinthe
followingillustrations.
3
4
2
1
StepScrew(quantity)Color
Torque
3
M2×5mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
1160Speakerassembly
Foraccess,removetheseFRUsinorder:
•“1020Batterypack”onpage72
•“1030Largebottomcover”onpage73
•“1040Smallbottomcover”onpage74
•“1050Opticaldriveoroptical-drivebaybezel”onpage75
•“1070Harddiskdriveassemblyorsolid-statedriveassembly”onpage77
•“1080WirelessLANcard”onpage79
•“1090Coin-cellbattery”onpage81
•“1110Keyboard”onpage81
•“1120Keyboardbezelassembly”onpage83
•“1130Systemboardandthermalfan”onpage86
•“1140dc-in/USB-connectorboardwithcable”onpage91
Chapter9.RemovingorreplacingaFRU93
